IC Integrated Circuits ADUM1420BRWZ

Name: IC Integrated Circuits ADUM1420BRWZ
Brand: IC Integrated Circuits ADUM1420BRWZ
SKU: ADUM1420BRWZ
Rating: 4.7 (119 reviews)

Product Details:
Place of Origin:	USA
Model Number:	ADUM1420BRWZ
Payment & Shipping Terms:
Minimum Order Quantity:	50PCS
Price:	RFQ
Packaging Details:	ESD/Vacuum/Foam/Cartons
Delivery Time:	Immediately
Payment Terms:	T/T, Western Union, escrow, Paypal, Visa, MoneyGram
Supply Ability:	RFQ

Contact Now

Specifications Product Description Request A Quote

Specifications

Product Category :: Gate Drivers

Rise / Fall Time (Typ) :: 25ns, 25ns (Max)

Voltage - Supply :: 12 V ~ 18 V

@ Qty :: 0

Mounting Type :: Surface Mount

Current - DC Forward (If) (Max) :: -

Manufacturer :: ADI / Analog Devices Inc.

Minimum Quantity :: 81

Factory Stock :: 0

Operating Temperature :: -40°C ~ 105°C

Current - Peak Output :: 100mA

Common Mode Transient Immunity (Min) :: 75kV/µs

Voltage - Isolation :: 1667Vrms

Supplier Device Package :: 28-SOIC

Pulse Width Distortion (Max) :: 8ns

Part Status :: Obsolete

Current - Output High, Low :: -

Packaging :: Tube

Number Of Channels :: 4

Voltage - Forward (Vf) (Typ) :: -

Propagation Delay TpLH / TpHL (Max) :: 128ns, 128ns

Package / Case :: 28-SOIC (0.295", 7.50mm Width)

Technology :: Magnetic Coupling

Approvals :: -

Series :: ICoupler®
