IC Integrated Circuits ADG1308BRZ-REEL7

Product Details:
Place of Origin:	USA
Model Number:	ADG1308BRZ-REEL7
Payment & Shipping Terms:
Minimum Order Quantity:	50PCS
Price:	RFQ
Packaging Details:	ESD/Vacuum/Foam/Cartons
Delivery Time:	Immediately
Payment Terms:	T/T, Western Union, escrow, Paypal, Visa, MoneyGram
Supply Ability:	RFQ

Contact Now

Specifications Product Description Request A Quote

Specifications

Packaging :: Tape & Reel (TR)

Product Category :: Multiplexer Switch ICs

Channel-to-Channel Matching (ΔRon) :: 5 Ohm

Switch Time (Ton, Toff) (Max) :: 100ns, 100ns

Current - Leakage (IS(off)) (Max) :: 1NA

Supplier Device Package :: 16-SOIC

Package / Case :: 16-SOIC (0.154", 3.90mm Width)

Part Status :: Active

Operating Temperature :: -40°C ~ 105°C (TA)

Voltage - Supply, Single (V+) :: 5 V ~ 16.5 V

Number Of Circuits :: 1

Multiplexer/Demultiplexer Circuit :: 8:01

Crosstalk :: -80dB @ 1MHz

Manufacturer :: ADI / Analog Devices Inc.

Channel Capacitance (CS(off), CD(off)) :: 15pF, 20pF

Switch Circuit :: -

Series :: -

Voltage - Supply, Dual (V±) :: ±5 V ~ 16.5 V

-3db Bandwidth :: 500MHz

On-State Resistance (Max) :: 210 Ohm

Charge Injection :: 2pC

Product Description
