IC Integrated Circuits ISO5452QDWRQ1 SOIC-16 Isolated Gate Drivers

Product Details:
Place of Origin: USA
Brand Name: TI
Model Number: ISO5452QDWRQ1
Payment & Shipping Terms:
Minimum Order Quantity: 50PCS
Price: RFQ
Packaging Details: ESD/Vacuum/Foam/Cartons
Delivery Time: Immediately
Payment Terms: T/T, Western Union, escrow, Paypal, Visa, MoneyGram
Supply Ability: RFQ
Specifications Product Description Request A Quote
Specifications
Specifications
RoHS: PB Free
Mounting Style: SMD/SMT
Package: SOIC-16
Series: ISO5452-Q1
Factory Pack Quantity: 2000
Product Type: Isolated Gate Drivers
Product Description

IC Integrated Circuits ISO5452QDWRQ1 SOIC-16 Isolated Gate Drivers



Product Description:

The ISO5452-Q1 is a 5.7-kVRMS, reinforced isolated gate driver for IGBTs and MOSFETs with split outputs, OUTH and OUTL, providing 2.5-A source and 5-A sink current. The input side operates from a single 2.25-V to 5.5-V supply. The output side allows for a supply range from minimum 15 V to maximum 30 V. Two complementary CMOS inputs control the output state of the gate driver. The short propagation time of 76 ns assures accurate control of the output stage. An internal desaturation (DESAT) fault detection recognizes when the IGBT is in an overcurrent condition. Upon a DESAT detect, a Mute logic immediately blocks the output of the isolator and initiates a soft-turn-off procedure which disables OUTH, and pulls OUTL to low over a time span of 2 μs. When OUTL reaches 2 V with respect to the most negative supply potential, VEE2, the gate driver output is pulled hard to VEE2 potential, turning the IGBT immediately off.



Application:

• Isolated IGBT and MOSFET Drives in: – HEV and EV Power Modules – Industrial Motor Control Drives – Industrial Power Supplies – Solar Inverters – Induction Heating



Parameter Table:

Product Attribute Attribute Value
Manufacturer: Texas Instruments
Product Category: Isolated Gate Drivers
RoHS: YES
Brand: Texas Instruments
Mounting Style: SMD/SMT
Operating Supply Current: 2.8 mA
Output Current: 5 A
Output Voltage: 15 V to 30 V
Package / Case: SOIC-16
Series: ISO5452-Q1
Shutdown: Shutdown
Factory Pack Quantity: 2000
Subcategory: PMIC - Power Management ICs
